Product Number: 83393

Electronic, 2 C #20 Str TC, FEP Ins, OS, Silicone Jkt, AWM 4516

Name: Belden 83393
Brand: Belden
SKU: 83393

High Temperature Electronic, 2 Conductor 20AWG (7x28) Tinned Copper, FEP Insulation, Overall Beldfoil® Shield, Silicone Outer Jacket, AWM 4516

Ships from and sold by A5 IT.

Part numbers

83393 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Footnote	Order
83393 004500	Yellow	Reel	500 ft	612825204572	C	Order online

Suitable Applications	extreme high/low temperature environments; low voltage analog signals (4-20ma, 0-10v, ...); low voltage control (24v, ...); line level audio; voice communications; panel wiring

Overall Cable Diameter (Nominal)	0.242 in (6.15 mm)

Element	Conductor(s)
Material	FEP - Fluorinated Ethylene Propylene
Nom. Thickness	0.020 in (0.51 mm)
Nom. Insulation Diameter	0.077 in (2.0 mm)
Color Code	Black, Red

Shield Type	Material	Coverage	Drainwire Type
Tape	Textile (Conductive)	100%
Tape	Bi-Laminate (Alum+Nomex®)	100%	20 AWG (7x28) TC

Nom Outer Shield DCR	8.49 Ohm/1000ft (27.9 Ohm/km)

Element	Conductor(s)
Nom. Conductor DCR	11.2 Ohm/1000ft
Nom. Capacitance Cond-to-Cond	22 pF/ft (72 pF/m)
Nom. Capacitance Cond-to-Other (Conds + Shield)	40 pF/ft (130 pF/m)
Nom. Inductance	0.2 μH/ft (0.66 μH/m)
Max. Current	3.8 Amps per Conductor at 25oC

UL Voltage Rating	600 V (UL AWM 4516)
Voltage Rating	2000 V DC (Through Jacket)

Max. Pull Tension	37.8 lbs (17.1 kg)
Bulk Cable Weight	36 lbs/1000ft

UL Temperature	150°C
Operating	-70°C to +150°C

Stationary Min.	2.42 in (61.5 mm)
Installation Min.	2.42 in (61.5 mm)

Environmental Suitability	Indoor
Sustainability	CA Prop 65
Flammability / Reaction to Fire	VW-1 (Singles)
AWM Compliance	AWM 4516
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC Compliance	China RoHS II (GB/T 26572-2011)
