Lead Wire, 0.375mm2 Str BC, PVC Ins, 70°C
12x0.2B PVC VMDS 70C
- Availability
- EMEA
- Status
- Active
- Orderable items
- 2
Part numbers
BE41436 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | EAN | Order |
|---|---|---|---|---|---|
| BE41436.004000 | Black | Reel | 4,000 m | 8719605025784 | Order online |
| BE41436.014000 | Black | Reel | 4,000 m | 8719605025791 | Order online |
Specifications
Product Overview
| Suitable Applications | IEC 189-3, VMDS 70C |
|---|
Construction Details
Conductor
| Stranding | Stranded |
|---|---|
| Material | BC - Bare Copper |
Insulation
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Insulation Diameter | 1.9 mm (0.075 in) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 52 Ohm/km |
|---|
Standards and Compliance
| Environmental Suitability | Indoor |
|---|---|
| European Directive Compliance | EU CE Mark |
History
| Update and Revision | Revision Number: 0.153 Revision Date: 09-07-2025 |
|---|
