Lead Wire, 0.44mm2 Str BC, PVC Ins, 70°C
14x0.2B PVC 70C
- Availability
- EMEA
- Status
- Active
- Orderable items
- 11
Part numbers
BE41231 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.
| Item # | Color | Putup Type | Length | EAN | Order |
|---|---|---|---|---|---|
| BE41231.003000 | Black | Reel | 3,000 m | 8719605025241 | Order online |
| BE41231.103000 | Blue | Reel | 3,000 m | 8719605025333 | Order online |
| BE41231.063000 | Brown | Reel | 3,000 m | 8719605025302 | Order online |
| BE41231.093000 | Gray | Reel | 3,000 m | 8719605025326 | Order online |
| BE41231.083000 | Red | Reel | 3,000 m | 8719605025319 | Order online |
| BE41231.053000 | Violet | Reel | 3,000 m | 8719605025296 | Order online |
| BE41231.033000 | White | Reel | 3,000 m | 8719605025272 | Order online |
| BE41231.013000 | White, Green Ring | Reel | 3,000 m | 8719605025258 | Order online |
| BE41231.023000 | White, Red Ring | Reel | 3,000 m | 8719605025265 | Order online |
| BE41231.043000 | Yellow | Reel | 3,000 m | 8719605025289 | Order online |
| BE41231.163000 | Yellow, Green Ring | Reel | 3,000 m | 8719605025340 | Order online |
Specifications
Product Overview
| Suitable Applications | IEC 189-3 Equipment wire 70C |
|---|
Construction Details
Conductor
| Stranding | Stranded |
|---|---|
| Material | BC - Bare Copper |
Insulation
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nom. Insulation Diameter | 2.05 mm (0.0807 in) |
Electrical Characteristics
Electricals
| Max. Conductor DCR | 45 Ohm/km |
|---|
Standards and Compliance
| Environmental Suitability | Indoor |
|---|---|
| European Directive Compliance | EU CE Mark |
History
| Update and Revision | Revision Number: 0.143 Revision Date: 09-07-2025 |
|---|
