Speaker Cable, 4C 4mm2 Str BC, LSZH Jkt
Speaker Cable, 4 Conductor 4mm2 Stranded Bare Copper, LDPE Insulation, LSZH Jacket
- Availability
- Asia Pacific
- Status
- Active
Specifications
Product Overview
| Suitable Applications | Security System, Intercom/PA, Audio/Speaker |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 9.7 mm (0.38 in) |
|---|
Conductor
| Size | 4 mm2 |
|---|---|
| Stranding Class | Class 5 |
| Material | BC - Bare Copper |
Insulation
| Material | PE - Polyethylene |
|---|---|
| Color Code | Black, Red, White, Green |
Outer Jacket
| Material | LSZH - Low Smoke Zero Halogen (Flame Retardant) |
|---|
Electrical Characteristics
Electricals
| Max. Conductor DCR | 4.95 Ohm/km (1.51 Ohm/1000ft) |
|---|
Voltage
| UL Voltage Rating | 300 V |
|---|
Mechanical Characteristics
Temperature
| Operating | - 20°C To + 75°C |
|---|
Standards and Compliance
| Environmental Suitability | Sunlight Resistance, UV Resistance |
|---|---|
| Flammability / Reaction to Fire | IEC 60332-1-2 |
| ISO/IEC Compliance | IEC 60228 |
| European Halogen Free Standards | IEC 60754-1 - Halogen Amount = ≤ 5 mg/g, IEC 60754-2 - Halogen Acid Gas Amount - Max. Conductivity = 10 μS/mm, IEC 60754-2 - Halogen Acid Gas Amount - Min. pH = 4.3 |
History
| Update and Revision | Revision Number: 0.4 Revision Date: 11-18-2025 |
|---|
