Speaker Cable, 2 Conductor 2.5 mm2, BC, Unshielded
Highly Flexible Speaker Cable, 2 core 2.5 mm2 stranded bare copper conductors with TPE insulation, TPE jacket
- Availability
- Asia Pacific
- Status
- Active
Specifications
Physical Characteristics (Overall)
| Conductor Count | 2 |
|---|---|
| Material | TPE |
Conductor
| AWG | 2.5 mm2 |
|---|---|
| Stranding | 77x0.2 mm |
| Material | BC - Bare Copper |
| No. of Conductors | 2 |
Insulation
| Material | TPE - Thermoplastic Elastomer |
|---|
Color Chart
| Color |
|---|
| Black |
| White |
Outer Shield
| Material | No Shield |
|---|
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|---|
| Nominal Diameter | 8.40 mm |
| Separator Material | non-Woven Tape |
Electrical Characteristics
Conductor DCR
| Max. Conductor DCR | 8.62 Ohm/km |
|---|
Temperature Range
| Operating Temperature Range | -25°C to +75°C |
|---|
Mechanical Characteristics
| UV Resistance | Yes |
|---|
Applicable Environmental and Other Programs
| Environmental Space | Indoor |
|---|---|
| EU Directive 2011/65/EU (RoHS 2) | Yes |
Flammability, LS0H, Toxicity Testing
| IEC Flammability | IEC 60332-1-2 |
|---|
History
| Update and Revision | Revision Number: 0.39 Revision Date: 02-15-2024 |
|---|
