Product Number: 9451PS4

Audio Snake Cable, 4 Pair 22 AWG, TC, Indiv. Shielded, CMP

Audio Snake Cable, 4 Pair 22 AWG tinned copper pairs, FEP insulation, drain, individually shielded with Beldfoil® bonded to numbered PVC jackets so both strip simulteaneously, Plenum Flamarrest® jackets, Banana Peel construction

Availability: Global
Status: Active
Orderable items: 1

Ships from and sold by A5 IT.

Part numbers

9451PS4 is a product family. Each item number below is a separate orderable part — colour, put-up and length differ.

Item #	Color	Putup Type	Length	UPC	Order
9451PS4 0101000	Black	Reel	1,000 ft	612825253105	Order online

Specifications

Product Overview

Suitable Applications	Recording Studio, Radio Broadcast, Sports Stadium, Nurse Call

Construction Details

Overall Cable Diameter (Nominal)	.306 in (7.77 mm)

Conductor

Size	22
Stranding	7x30
Material	TC - Tinned Copper
No. of Pairs	4

Insulation

Material	FEP - Fluorinated Ethylene Propylene
Nom. Insulation Diameter	0.044 in (1.1 mm)
Color Code	Black & Red

Inner Jacket

Element	Individual
Material	PVC - Polyvinyl Chloride
Nom. Diameter	.127 in (3.23 mm)
Color	Black

Outer Shield

Shield Type	Tape
Material	Bi-Laminate (Alum+Poly)
Coverage	100%

Outer Jacket

Material	Banana Peel (No Overall Jacket)
Material Trade Name	Flamarrest®

Electrical Characteristics

Delay

Nom. Velocity of Prop.	69%

Voltage

UL Voltage Rating	300 V RMS

Mechanical Characteristics

Max. Pull Tension	108 lbs (49.0 kg)
Bulk Cable Weight	68 lbs/1000ft (100 kg/km)

Temperature

UL Temperature	60°C
Operating	-20°C To +75°C

Standards and Compliance

Environmental Suitability	Indoor - Plenum, Indoor
Flammability / Reaction to Fire	NFPA 262
NEC / UL Compliance	CMP
CEC / C(UL) Compliance	CMP.
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC Compliance	China RoHS II (GB/T 26572-2011)
