Flexible Audio Cable 2C #24 Str BC, Beldfoil® shielded(Z-Fold), PVC Jkt
Flexible Audio Cable 2C #24 Str BC, Beldfoil® shielded(Z-Fold), PVC Jkt
- Availability
- Asia Pacific
- Status
- Active
Specifications
Product Overview
| Suitable Applications | Line level audio; Low voltage analog signals and control |
|---|
Construction Details
| Overall Cable Diameter (Nominal) | 4.5 mm (0.18 in) |
|---|
Conductor
| Element | Conductor(s) |
|---|---|
| No. of Elements | 2 |
| Size | 24 AWG |
| Stranding Class | Class 6 |
| Material | BC - Bare Copper |
Insulation
| Material | PE - Polyethylene |
|---|---|
| Nom. Insulation Diameter | 1.20 mm (0.0472 in) |
| Color Code | Blue, White |
Outer Shield
| Shield Type | Tape |
|---|---|
| Material | Bi-Laminate (Alum+Poly) |
| Drainwire Type | 26 AWG (7x34) TC |
Outer Jacket
| Material | PVC - Polyvinyl Chloride |
|---|
Electrical Characteristics
Electricals
| Max. Conductor DCR | 87.6 Ω/km @ 20°C |
|---|
Mechanical Characteristics
| Bulk Cable Weight | 26 Kg/km |
|---|
Temperature
| Operating | -20°C To +60°C |
|---|
Standards and Compliance
| Flammability / Reaction to Fire | VW-1 |
|---|---|
| European Directive Compliance | EU Directive 2011/65/EU (RoHS 2) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
History
| Update and Revision | Revision Number: 0.6 Revision Date: 11-18-2025 |
|---|
